Harvia Cilindro PC110E 10.5kW Electric Sauna Heater – Premium Pillar Design for Large Sauna Rooms
The Harvia Cilindro PC110E is a powerful, pillar-style electric sauna heater designed to bring both style and performance to larger sauna spaces. With a sleek stainless steel frame and vertical design, this 10.5kW unit is built to efficiently heat sauna rooms up to 636 cubic feet.
The Cilindro's open, grate-style construction allows users to customize their steam experience. Pouring water along the sides results in a softer steam, while pouring directly on top of the stone pillar delivers a sharper, more intense burst. With its visually striking design and massive rock capacity, the PC110E is both a functional and aesthetic centerpiece in any sauna.
Ideal for side-wall or corner installation, the PC110E requires a Harvia Xenio control system (sold separately) for operation and is available in a 240V single-phase configuration.
🔑 Key Features:
-
10.5kW electric sauna heater
-
Heats sauna rooms from 141 to 636 cu. ft.
-
Sleek, vertical pillar design with stainless steel construction
-
Grate-style exterior for adjustable steam intensity
-
Side-wall or corner installation
-
Requires minimum 264 lbs of sauna stones (6 boxes – AC3000)
-
We recommend an additional box for ideal stone selection (freight charges may apply)
-
Direct rock-to-heating element contact for efficient, consistent heat
-
Industrial-grade, serviceable stainless steel heating elements
-
Operates on 240V, single-phase power
-
Dimensions: 16"W x 15"D x 45"H (406mm x 381mm x 1143mm)
-
UL Listed
-
Made in Finland
-
2-Year Warranty (Residential Use)
What’s Included:
-
Harvia Cilindro PC110E Sauna Heater
-
Installation and Operation Manual
-
2-Year Consumer Warranty
Manufacturer’s Note:
Proper stone placement and regular maintenance are essential for safe operation and to maintain warranty coverage. Stones are sold separately.
Specifications
| Model | Cilindro PC110E |
|---|---|
| Kilowatt Rating (KW) | 10.5 KW |
| Primary Fuel | Electric |
| Minimum Adjusted Cubic Feet | 141 |
| Maximum Adjusted Cubic Feet | 636 |
| Voltage | 240 |
| Phase | 1 |
| Nominal Amps | 43.75 Amps |
| Heater Weight | 46.3 lbs |
| Shipping Weight with Sauna Stones | 310.3 lbs |
| Width In Inches | 16" (406mm) |
| Depth In Inches | 15" (381mm) |
| Height In Inches | 45" (1143mm) |
Shipping
For more information, feel free to contact us at: contact@radiantdollhealth.com
Manual
Harvia Cilindro E Series IOM 2022.pdf
Harvia-Cilindro-PC110E-DATASHEET-HPCS11U1H.pdf
Harvia Sauna Stones Update 6-22.pdf
