Harvia Cilindro PC80E 8kW Electric Sauna Heater – Pillar-Style Design for Medium to Large Sauna Rooms
The Harvia Cilindro PC80E is a modern pillar-style electric sauna heater designed to deliver powerful, even heat in sauna rooms up to 431 cubic feet. With a visually striking vertical design and open stainless steel grate, the PC80E allows bathers to tailor their steam experience—softer when water is poured on the sides, and sharper when poured directly over the top.
Ideal for side-wall or corner installation, the Cilindro combines form and function for both residential and light commercial use. Its large rock capacity enhances thermal performance and ensures consistent heat delivery.
This unit is available in 240V single-phase or 208V three-phase configurations and requires a Harvia Xenio control system (sold separately) for operation.
🔑 Key Features:
-
8kW electric sauna heater
-
Heats sauna rooms from 141 to 431 cu. ft.
-
Pillar-style design with open stainless steel grate
-
Customizable steam intensity
-
Side-wall or corner installation
-
Available in 240V single-phase or 208V three-phase
-
Requires a minimum of 200 lbs of sauna stones (5 boxes – AC3000)
-
We recommend an extra box for selecting ideal stone shapes (freight charges may apply)
-
Direct rock-to-heating element contact for efficient heat transfer
-
Industrial-grade, serviceable stainless steel heating elements
-
Made in Finland
-
Dimensions: 14"W x 13"D x 40"H (355mm x 330mm x 1016mm)
-
UL Listed
-
2-Year Warranty (Residential Use)
What’s Included:
-
Harvia Cilindro PC80E Sauna Heater
-
Installation and Operation Manual
-
2-Year Consumer Warranty
Manufacturer’s Note:
Sauna heater stones are critical to safe and effective operation. Proper stone selection, placement, and routine maintenance are required to maintain warranty coverage.
Specifications
| Model | Cilindro PC80E |
|---|---|
| Kilowatt Rating (kW) | 8 kW |
| Primary Fuel | Electric |
| Minimum Adjusted Cubic Feet | 141 |
| Maximum Adjusted Cubic Feet | 431 |
| Voltage | 240 |
| Phase | 1 |
| Nominal Amps | 33.4 Amps |
| Heater Weight | 37.5 lbs |
| Shipping Weight with Sauna Stones | 257.5 lbs |
| Width In Inches | 14" (355mm) |
| Depth In Inches | 13" (330mm) |
| Height In Inches | 40" (1016mm) |
