Harvia Cilindro PC90E 9kW Electric Sauna Heater – Modern Pillar Design for Larger Sauna Rooms
The Harvia Cilindro PC90E is a sleek, steel pillar-style electric sauna heater designed for sauna rooms up to 494 cubic feet. With its impressive vertical build and generous stone capacity, this heater offers both aesthetic appeal and powerful steam performance.
The open, grate-style exterior allows bathers to tailor the steam experience: enjoy a softer steam when pouring water along the sides or a more intense burst when pouring directly on top. This flexibility makes the Cilindro a favorite for those seeking a truly personalized sauna session.
Ideal for corner or side-wall installation, the Cilindro PC90E blends modern design with authentic Finnish functionality. It requires a Harvia Xenio control unit for operation (sold separately).
🔑 Key Features:
-
9kW electric sauna heater
-
Designed for sauna rooms from 141 to 494 cu. ft.
-
Vertical, pillar-style construction with stainless steel outer shell
-
Corner or side-wall installation
-
Large rock capacity for customizable steam output
-
Requires minimum 200 lbs of sauna stones (5 boxes – AC3000)
-
We recommend an extra box for ideal stone selection (additional freight may apply)
-
Direct rock-to-heating element contact for efficient heat distribution
-
Industrial-grade, serviceable stainless steel heating elements
-
Made in Finland
-
Dimensions: 14"W x 13"D x 40"H (355mm x 330mm x 1016mm)
-
UL Listed
-
2-Year Warranty (Residential Use)
What’s Included:
-
Harvia Cilindro PC90E Sauna Heater
-
Installation & Operation Manual
-
2-Year Consumer Warranty
Manufacturer’s Note:
Sauna stones are essential to the unit’s safety and function. Proper stone placement and routine maintenance are required to maintain warranty coverage.
Specifications
| Model | Cilindro PC90E |
|---|---|
| Kilowatt Rating (KW) | 9 KW |
| Primary Fuel | Electric |
| Minimum Adjusted Cubic Feet | 141 |
| Maximum Adjusted Cubic Feet | 494 |
| Voltage | 240 |
| Phase | 1 |
| Nominal Amps | 37.5 Amps |
| Heater Weight | 37.5 lbs |
| Shipping Weight with Sauna Stones | 257.5 lbs |
| Width In Inches | 14" (360mm) |
| Depth In Inches | 13" (340mm) |
| Height In Inches | 40" (1010mm) |
Shipping
For more information, feel free to contact us at: contact@radiantdollhealth.com
Manual
Harvia Cilindro E Series IOM 2022.pdf
Harvia-Cilindro-PC90E-DataSheet.pdf
Harvia Sauna Stones Update 6-22.pdf
