The ThermaSol Hydrovive Wellness Steam package with SignaTouch provides a comprehensive home steam experience. This package includes a SignaTouch Round control with a 5" capacitive touch screen, HydroVive 18 Rainhead, and SteamVection Steamhead. The SignaTouch Round control is constructed with black acrylic, features a full-color display with 16.7 million colors and a resolution of 480 x 800 pixels, and operates via single touch interface. It measures 5.7" in width, 1.25" in depth, and 4.8" in height, employing a 5" full-color capacitive touchscreen designed for in-shower installation. Its features include a Bluetooth built-in interface, time and temperature control, memory and two customizable user settings, and a lifetime warranty covering parts and labor for 2 years.
The HydroVive 18 system is a ceiling-mounted module crafted from machined brass, with dimensions of 18" width, 8" depth, and 18" height, weighing 37 lbs. It integrates lighting, sound, and rainhead functionalities within a single self-contained unit, featuring full-spectrum LED lighting with up to 1600 lumens, 200 full-color LED lights suitable for mood and chromatherapy, and stereo sound with a 100Watt RMS amplifier and Bluetooth v4.2. The system is equipped with 300 neoprene jets, operating at 15-80 PSI with a flow rate of 1.8 GPM, and is CEC approved.
The SteamVection Steamhead is a brass alloy device available in round or square styles, with dimensions of approximately 1.75" in diameter or width, and 1.75" in height or depth. It features a whisper-quiet operation, a brass alloy construction, and an essential oil well for aromatherapy (sold separately). The steam head is designed for floor-to-ceiling temperature consistency and is available in 15 designer finishes.
🔑 Key Features
✅ 5" SignaTouch Control
- Steam shower control with 5" touchscreen
- 15 designer finish options
- Bluetooth built-in for audio streaming
- Operates digital shower valve (sold separately)
- Controls SteamVection Steamhead (sold separately)
- Operates Serenity Light, Sound, Rainhead (sold separately)
- Time and temperature control with memory settings
- Display shows date and time
- Dimensions: 5 3/4" x 4" x 3/4"
- Lifetime warranty (parts and labor, 2-year coverage)
HydroVive 18 Rainhead & System
- Ceiling-mounted light, sound, and rainhead system
- Full-spectrum LED lighting, up to 1600 lumens
- 200 full-color luminous LEDs for mood lighting
- Chromatherapy preset and customizable colors
- Distortion-free sound with 100W RMS amplifier and Bluetooth v4.2
- 300 neoprene jets, 1.8 GPM flow, operating at 15-80 PSI
- System dimensions: 18" W x 8" D x 18" H, weight 37 lbs
- CEC approved
- Engineered, designed, and crafted in the U.S.A.
- Includes lighting, sound, and rainhead components; accessories such as lubricants and installation instructions included
SteamVection Steam Head
- Brass alloy construction for durability
- Available in round or square styles
- Dimensions: approximately 1.75" diameter or width x 1.75" height/depth
- Floor-to-ceiling temperature consistency
- Whisper-quiet operation
- Essential oil well for aromatherapy (sold separately)
- Five-year manufacturer warranty
📦 What’s Included
- SignaTouch Round control panel with silicone interface, installation manual, warranty, and static cling warning label
- HydroVive 18 ceiling system with wood screws, silicone, 25' yellow M12 cable, 25' audio cable, installation instructions, and warranty
- SteamVection Steam Head in selected finish, silicone, lubricant, installation manual, and warranty
Specifications
| Model | WHSTPSR |
|---|
| Model | STCM |
|---|---|
| Construction | Black Acrylic |
| Display | 5" Capacitive Touch Screen |
| Display Full Color | 16.7M |
| Display resolution | 480 x 800 |
| Interface | Single Touch |
| Shipping Weight | 1.25 lbs |
| Width | 5.7" |
| Depth | 1.25" |
| Height | 4.8" |
| Model | HVLSRSQ |
|---|---|
| Construction Material | Machined Brass |
| Function Lights | 200 Full-color luminous LED |
| Water Supply | 3/8", 40-80 PSI, 1.8GPM |
| Water Jets | 300 |
| CEC Approved | Yes |
| Amplifier | 100Watt RMS |
| Digital Signal Processor | Built-in |
| Weight | 37 lbs |
| Width | 18" |
| Depth | 8" |
| Height | 18" |
| Model | SteamVection |
|---|---|
| Material | Brass Alloy |
| Connection | 1/2" NPT |
| Shipping Weight | 1 lb |
| Width | 1.75" |
| Depth | 1.9" |
| Height | 1.75" |
Shipping & Manual Information
For shipping inquiries, please contact us at contact@radiantdollhealth.com.
Access the Installation and Operation Manual.
Download the Specification Sheet.
Refer to the Finish Availability.
